产品说明：

SURFACEMOUNTGENERALPURPOSE RECTIFIERS

Part Number	Peak Repetitive Reverse Voltage	Max. Average Rectified Current		Max. Peak Forward Surge Current	Max. Forward Voltage Drop		Max. Reverse Current		PDF
	VRRM	Io @ TL		IFSM	VF @ IF		IR @ VR
	V	A	℃	A	V	A	mA	V
1ASURFACEMOUNTGENERALPURPOSE / SS
SS4001	50	1	75	30	1.1	1	5	50
SS4002	100	1	75	30	1.1	1	5	100
SS4003	200	1	75	30	1.1	1	5	200
SS4004	400	1	75	30	1.1	1	5	400
SS4005	600	1	75	30	1.1	1	5	600
SS4006	800	1	75	30	1.1	1	5	800
SS4007	1000	1	75	30	1.1	1	5	1000
1ASURFACEMOUNTGENERALPURPOSE / DO-214AC(SMA)
SM4001A	50	1	75	30	1	1	5	50
SM4002A	100	1	75	30	1	1	5	100
SM4003A	200	1	75	30	1	1	5	200
SM4004A	400	1	75	30	1	1	5	400
SM4005A	600	1	75	30	1	1	5	600
SM4006A	800	1	75	30	1	1	5	800
SM4007A	1000	1	75	30	1	1	5	1000
1ASURFACEMOUNTGENERALPURPOSE / SM-1
SM4001	50	1	75	30	1	1	5	50
SM4002	100	1	75	30	1	1	5	100
SM4003	200	1	75	30	1	1	5	200
SM4004	400	1	75	30	1	1	5	400
SM4005	600	1	75	30	1	1	5	600
SM4006	800	1	75	30	1	1	5	800
SM4007	1000	1	75	30	1	1	5	1000
2ASURFACEMOUNTGENERALPURPOSE / DO-214AC(SMA)
S2AA	50	2	100	60	1.1	2	5	50
S2BA	100	2	100	60	1.1	2	5	100
S2DA	200	2	100	60	1.1	2	5	200
S2GA	400	2	100	60	1.1	2	5	400
S2JA	600	2	100	60	1.1	2	5	600
S2KA	800	2	100	60	1.1	2	5	800
S2MA	1000	2	100	60	1.1	2	5	1000
