Part Number

Peak Repetitive Reverse Voltage

Max.
Average
Rectified
Current

Max. Peak Forward Surge Current

Max.
Forward
Voltage
Drop

Max.
Reverse
Current

Max. Reverse Recovery Time

PDF

VRRM

Io @ TL

IFSM

VF @ IF

IR @ VR

trr

V

A

℃

A

V

A

mA

V

nS

 1ASURFACE MOUNT FAST RECOVERY / SS

SSF101

50

1

50

30

1.3

1

5

50

150

SSF102

100

1

50

30

1.3

1

5

100

150

SSF103

200

1

50

30

1.3

1

5

200

150

SSF104

400

1

50

30

1.3

1

5

400

150

SSF105

600

1

50

30

1.3

1

5

600

250

SSF106

800

1

50

30

1.3

1

5

800

500

SSF107

1000

1

50

30

1.3

1

5

1000

500

 1ASURFACE MOUNT FAST RECOVERY / DO-214AC(SMA)(1)

SMF101A

50

1

55

30

1.3

1

5

50

150

SMF102A

100

1

55

30

1.3

1

5

100

150

SMF103A

200

1

55

30

1.3

1

5

200

150

SMF104A

400

1

55

30

1.3

1

5

400

150

SMF105A

600

1

55

30

1.3

1

5

600

250

SMF106A

800

1

55

30

1.3

1

5

800

500

SMF107A

1000

1

55

30

1.3

1

5

1000

500

 1ASURFACE MOUNT FAST RECOVERY / DO-214AC(SMA)(2)

SM4933A

50

1

55

30

1.2

1

5

50

* 200

SM4934A

100

1

55

30

1.2

1

5

100

* 200

SM4935A

200

1

55

30

1.2

1

5

200

* 200

SM4936A

400

1

55

30

1.2

1

5

400

* 200

SM4937A

600

1

55

30

1.2

1

5

600

* 200

  * trr Test Condition: IF=1.0A, VR=30V.

 1ASURFACE MOUNT FAST RECOVERY / SM-1

SMF101

50

1

55

30

1.3

1

5

50

150

SMF102

100

1

55

30

1.3

1

5

100

150

SMF103

200

1

55

30

1.3

1

5

200

150

SMF104

400

1

55

30

1.3

1

5

400

150

SMF105

600

1

55

30

1.3

1

5

600

250

SMF106

800

1

55

30

1.3

1

5

800

500

SMF107

1000

1

55

30

1.3

1

5

1000

500
